Complete Wiring Guide for Cole Hersee Solenoid Schematic Setup

For precise current control in automotive and industrial starter systems, use terminals S (start) and I (ignition) as primary activation points. Connect S directly to the ignition switch output, ensuring a 10-gauge or thicker wire to handle inrush current–typically 80–120 amps for 12V configurations. Terminal I should link to a fused circuit (15–20A) for protection during sustained engagement. Avoid shared grounds; dedicate a 4-gauge cable from the switch’s M (motor) terminal to the battery’s negative post.

Verify coil resistance before installation: 0.3–0.6 ohms for standard models, 0.8–1.2 ohms for high-amperage variants. Low resistance risks premature burnout; high readings indicate corroded contacts. Test continuity between B (battery) and M terminals during engagement. Readings below 50 milliohms confirm proper plunger travel. For 24V systems, double the wire gauge recommendations–6-gauge minimum for battery leads, 8-gauge for auxiliary circuits.

Polarity reversal causes instant failure. Label all connections: B (positive input), C (contact), R (remote trigger). Use dielectric grease on terminals B and C to prevent oxidation under high-current loads. For dual-switch setups (e.g., winch plus starter), isolate circuits with double-throw relays to prevent backfeed–voltage spikes exceed 14.5V during disengagement.

Electrical Relay Connection Guide for Automotive Applications

Connect the input terminal (30) directly to the battery’s positive terminal using 8-gauge wire for continuous-duty relays or 10-gauge for intermittent operation. Ensure the cable run avoids sharp edges, exhaust manifolds, and moving components–secure with adhesive-lined clamps every 12 inches. The control circuit terminal (85) requires a dedicated 16-gauge wire to the switch; confirm the switch rating matches the relay’s coil voltage (typically 12V) to prevent overheating. For marine or high-vibration environments, solder all connections and cover with heat-shrink tubing to seal against moisture.

• Activation Trigger: Terminal 86 links to ground–use a chassis point free of paint, rust, or corrosion, preferably within 18 inches of the relay. A star washer improves conductivity.
• Load Handling: Terminal 87 delivers power to accessories; fuse this line within 7 inches of the battery using a value 20% above the accessory’s peak draw (e.g., 30A fuse for a 25A winch). For dual-output relays, terminal 87a sits normally closed–verify application requirements to avoid unintended engagement.
• Voltage Drop Mitigation: Maintain total circuit resistance below 0.2Ω; test with a multimeter under load. Replace conductors if resistance exceeds 0.1Ω per foot of length.

Troubleshooting Relay Failures

If activation produces a clicking sound without load engagement:

1. Check terminal 30 for 12.6V+; voltage below 12V indicates a weak battery or undersized cable.
2. Measure coil resistance (terminals 85–86) with an ohmmeter–values outside 50–120Ω suggest a faulty relay.
3. Inspect terminals for oxidation; clean with a wire brush or replace connectors if pitted.
4. Test the switch by bypassing it with a jumper wire; persistent failure isolates the issue to the relay.

For high-current applications (e.g., engine starting), use a relay with silver-plated contacts rated for 200A+ and a suppression diode across the coil to absorb inductive spikes. Position the relay within 12 inches of the load to minimize voltage loss; mount on a grounded metal surface for heat dissipation. Avoid paralleling relays unless matched–uneven load distribution risks premature failure.

Key Elements of an Electromagnetic Switch Mechanism

Begin assessment by identifying the copper coil–typically wound around a ferromagnetic core. This component generates the magnetic field when current passes, so ensure wire gauge matches the application’s voltage rating: 12V systems require 16–18 AWG, while 24V setups need 14–16 AWG for reliable actuation.

Check the movable plunger, often made of soft iron or steel, positioned inside the coil. Its travel distance directly impacts contact pressure; standard automotive units allow 3–6mm, but high-load industrial variants may need 8–12mm to prevent arcing under heavy current. Verify clearance against the manufacturer’s specifications–even 0.5mm deviation can reduce lifespan by 30%.

Inspect the contact assembly next. High-quality switches use silver, silver-cadmium, or copper-tungsten for contacts to handle 100–300A spikes without welding. Avoid units with pure copper contacts in applications exceeding 150A continuous, as oxidation will increase resistance. For frequent cycling (over 50 daily operations), opt for sintered contacts to minimize pitting.

Examine the return spring–its tension determines the release threshold. A weak spring (under 5N) risks held-in failures, while excessive tension (over 15N) may prevent full engagement under low voltage. Measure spring force with a dynamometer during installation; adjust or replace if outside ±10% of the recommended value.

Housing and Environmental Considerations

The enclosure material dictates durability. Zinc-plated steel housings resist corrosion in underhood environments, but marine applications demand stainless steel (type 316) to withstand saltwater exposure. Polycarbonate components, found in some sealed units, crack under UV exposure–replace with glass-filled nylon for outdoor installations.

Sealing integrity prevents moisture ingress. Verify O-rings or gasket compression meets IP67 standards for submersion-resistant models. For non-sealed variants, apply dielectric grease to terminal connections; corrosion here accounts for 70% of failures in high-humidity regions. Use heat-shrink tubing over splices if modifying factory harnesses.

Electrical Interface and Troubleshooting

Terminal configuration varies by model–common layouts include spade, threaded stud, or quick-disconnect. Stud terminals handle higher current (up to 500A) but require torque of 10–15Nm to prevent hotspots. For 1/4″ spade connectors, crimp with a ratcheting tool and solder the joint if current exceeds 80A to avoid resistance build-up.

Diagnose failed activation by measuring coil resistance with a multimeter–values should align within ±15% of specifications (typically 2.5–5Ω for 12V coils). A shorted coil reads near 0Ω, while an open circuit shows infinite resistance. Replace the unit if readings deviate, as repairs rarely restore reliability.

Step-by-Step Connection Guide for Single-Starter Setups

Start with the battery terminal: attach the positive cable (minimum 4 AWG) to the input lug marked “BATT” or “30”. Secure with a 10mm bolt, ensuring no corrosion on the contact surface–clean with a wire brush if needed. Route the cable away from moving parts and heat sources, using loom tubing where exposed. For 12V systems, verify the battery delivers at least 700 CCA (cold cranking amps) before proceeding; insufficient power risks overheating the relay.

Components and Placement

• Primary relay unit: Mount within 18 inches of the starter motor using vibration-resistant hardware (e.g., stainless steel lock washers). Avoid plastic mounts–opt for metal brackets or direct chassis grounding.
• Control switch: Wire the activation circuit (key switch or push-button) to the “S” or “50” terminal. Use 14 AWG wire for the control path, but upgrade to 12 AWG if the run exceeds 10 feet to prevent voltage drop.
• Ground path: Connect the relay’s case to the chassis using a 6 AWG braided strap, not a single wire. Sand the contact points to bare metal and apply dielectric grease to prevent oxidation.

Test the circuit by bypassing the ignition system: jumper the “BATT” terminal directly to the “M” or “motor” terminal using a 200A fuse (not included in standard kits). The starter should engage immediately. If rotation is weak or intermittent, check for loose connections with a multimeter–voltage drop across terminals should not exceed 0.2V. For diesel engines, add a pre-heat circuit breaker (150A) upstream of the relay to handle higher inrush currents.

Identifying Common Connection Errors and Practical Solutions

Reverse polarity on the switching circuit often causes immediate failure of the relay mechanism. Check terminals marked “+” and “-” on the control side–accidental swaps burn out the coil. Use a multimeter in continuity mode before powering up: place probes on the control pins while toggling the switch. If resistance remains infinite, the path is broken; replace the relay if internal windings are open.

Error	Symptom	Verification	Fix
Loose power feed to main contacts	Intermittent engagement, no voltage at load	Measure incoming voltage at main lugs under load	Crimp new ring terminals, torque to 12 in-lbs
Incorrect gauge on remote trigger leads	Melting insulation, tripped breaker	Compare wire gauge to 10A max rating per circuit	Replace leads with 16AWG copper minimum
Ground path corruption	Slow activation, backfeeding electronics	Test between chassis ground and negative terminal	Clean mounting surface, use dielectric grease

Ignoring micro-arc erosion at contact points leads to premature degradation under 30A+ loads. Inspect the contact face under light–any discoloration or pitting indicates excessive resistance. Sand with 400-grit wet paper, then apply contact cleaner and operate the relay 5 times under no load to establish fresh metal-on-metal seating.

Adapting a Heavy-Duty Relay for Dual-Battery Setups

Start by selecting a relay with a continuous-duty rating of at least 200A–models like the 48530 or 48250 handle high current demands reliably. Connect the main battery’s positive terminal to the relay’s common post (typically marked “BAT” or “30”) using 2/0 AWG cable to minimize voltage drop. Ensure the secondary battery’s positive lead fastens to the normally open contact (labeled “S” or “87”), securing with an M8 stainless steel bolt and lock washer to prevent loosening under vibration.

Install a 15A inline fuse within 7 inches of the auxiliary battery’s positive terminal to protect the ignition circuit. Wire the relay’s coil activation post (marked “I” or “85”) to the ignition switch via 12 AWG wire, but add a diode (1N4007) in reverse bias between the coil and ground to suppress voltage spikes that degrade microelectronics. Ground the relay’s remaining coil post (“G” or “86”) directly to the chassis using a dedicated 4 AWG braided strap–avoid shared grounding points to eliminate noise interference.

Key Modifications for High-Current Applications

For winches or inverter systems exceeding 150A, replace standard copper lugs with tinned marine-grade terminals. Crimp connectors using a hydraulic press (minimum 12 tons) and solder joints with 60/40 rosin-core solder to prevent oxidation. Apply dielectric grease to all connections before final tightening–this reduces corrosion by 70% in saltwater environments. If ambient temperatures exceed 50°C (122°F), space the relay at least 10cm from heat sources and mount it vertically to optimize cooling airflow.

Integrate a manual override switch (SPST, 30A) between the ignition wire and relay coil to bypass automatic activation during cranking. Use waterproof boots over all exposed terminals (IP67-rated) and route wires through grommeted firewall openings. For systems with dual alternators, add a second relay in parallel, but ensure each has a dedicated 100A fuse to prevent backfeeding–voltage differentials above 0.3V between batteries indicate faulty isolation.
